The Titan Ice combines our best fog machine technology with the convenience of an integrated fog chiller. Using the power of ice to chill our specially formulated low-lying fog fluids, the Titan Ice creates an amazing, thick blanket of fog that is great for eerie graveyard effects, motion picture usage, plays and more!
EFFICIENT AND POWERFUL
Robust metal cases house the most efficient heater cores available giving you tremendous output. The Titan ICE features a 1700W core and a spacious Ice chamber to lay down a super thick carpet of fog!
BACKLIT DIGITAL LCD
LCD controls and timer functions allow for easy adjustment in the dark and simple menus that put an end to frantically studying the user manual like prepping for a college final.
NEUTRIK POWERCON TRUE1
A locking power cord connector that can be removed under live or load.
DMX input/output gives full board control for integration into more intricate scenes. You can also activate the fog machine simply with the included wireless remote. All our titan series foggers include a 2 year warranty on parts and service.
Length: 31 in. Box: 34 in.
Width: 15.4 in. Box: 18.1 in.
Height: 17.7 in. Box: 20 In.
Net Weight: 71 lbs. Gross: 80 lbs.Performance
Fluid consumption (100%): 25ml/min
Maximum operating time, maximum output: 200 Min.
Ready time: 4 Minutes
Continuous Output: Yes
Control and Programming
Control options: DMX, LCD Menu, Wireless on/off remote
Control parameters: Continuous or timer-controlled output
Variable output control, 0-100%
DMX channels: 2
External fluid control: Fluid sensing
DMX compliance: ANSI E1.11 – USITT DMX512-A
RDM compliance: ANSI/ESTA E1.20 RDM
Housing: Polymer-Cased Metal
Fluid pump: Dual oscillating piston, high pressure
Fluid reservoir: 5L drop-in reservoir
Remote Control: Wireless
AC Power: IP65 Rated Seetronic Powerkon
DMX, link mode in/out: 3 and 5-pin locking XLRElectrical
US Model:AC power: 120 V, 60 Hz
Main fuse: 15A, 250V
IP Rated Power, DMX, and Breaker Ports
Typical power and current: 1700 W @ 100%
*Measurements made at nominal voltage. Allow for a deviation of +/- 10%.:
Fluid reservoir, 5L Tank
Power input cable, US, 6 ft, IP65 Rated Seetronic Powerkon Power Cable
*Various sizes available – contact usr or see ‘Fluids’ product pages for details
