EW22G Soft-Mount Extractor

$5,198.00

The Extractor 22 (EW22) is designed to follow current NFPA-1851 guidelines.

Commercial Extractor tumbles PPE gear with a front load design
and soft-mount installation.

Contact us to Purchase

Part Number: EW22G

Description

STANDARD FEATURES
• Can wash 4 pieces of turnout gear per load
• Stainless steel inner tub (capacity: 3.7 cu. ft)
• Easy soft-mount installation
• With fewer overall moving parts; Promotes longer life expectancy
• Meets NFPA 1851:2020 Requirements
• Complete with manual/manufacturer’s warranty
• Hot and Cold hoses come with unit
• PPE Washing Programs: Spin Cycle G-Force Under 100 G’s
• Towels Washing Program: Spin Cycle G-Force 451 G’s
• A backflow preventer is built into the supply dispenser

ELECTRICAL
• Runs on 120 volts (watts per load: 110-160 watt hours)
• Fuse: 250V, 12 A (Time Delay)
• 6′ electrical cord with plug comes off the back of the extractor.

PLUMBING
• There is a 6′ flexible drain hose that comes off the back of the
extractor. The drain hose should be inserted into a 2″ standing
drain pipe or attached to a nearby slop sink or laundry tub.

WASH CYCLES (All Times are Approximate)

Blood Bourne

  • Hot wash cycle to be used with PPE gear disinfectant
    laundry solution
  • Cycle: Total time – 30 minutes

Outer Shells / Liners

  • NFPA 1851 warm wash cycle for PPE outer shells & liners
  • Cycle: Total time – 57 minutes

Cold

  • PPE cold wash cycle.
    Cycle: Total time – 52 minutes

Towels

  • Warm wash cycle for station towels & rags
  • *Do not wash personal or shower/bath towels in extractor
  • *Do not wash PPE gear on Towels program
  • Cycle: Total time – 47 minutes

Super Wash

  • Extended warm wash cycle for heavy soiled PPE gear
    Cycle: Total time – 63 minutes

**Water usage on average will be about 13-14 gallons per cycle. This will vary depending on water absorption of the fabric.

Fill time and drainage time is 4-5 gal/min

TECHNICAL SPECIFICATIONS
EW22G SOFT-MOUNT EXTRACTOR
Machine Type: Extractor
Product Name: Extractor 22G
Product No.: EW22G
Color: Gray

Main Data

  • Type Soft-Mount
  • Capacity, pieces turnout gear 4
  • Capacity (dry weight) lbs / kg 22 / 9.97
  • Interior capacity cu ft / L 3.7 / 104.77

Electrical Installation

  • Electrical connection 120v
  • Fuse 250v, 12 A (Time Delay)

Dimensions

  • Outer: width × depth × height in / cm 27 × 30.2 × 38.7 / 68.6 × 77.5 × 98.3
  • Depth with door fully open in / cm 52.6 / 133.6
  • Shipping dimensions in / cm 36 × 36 × 58 / 91.44 × 91.44 × 147.32

Weight

  • Weight lbs / kg 196 / 86.1
  • Shipping weight lbs / kg 250 / 133.39
