Hyperion D6 ‐ Dual Color ‐ 1600 Watts, 2 Color Smoke ‐ Upshot Fog Machine W/ Hex LEDS

$812.49

Forget everything you know about Upshot machines.  The 1600W Hyperion D6 has changed the rules.  The World’s First Variable Output Upshot machine allows you to control the size of the plume!

  • 1600W Upshot Fogger
  • Instant Stop Technology (IST)
  • Dual Zone LED – Inner and Outer Flame Technology
  • Low Fluid Sensing Technology
  • Max Height: 30’
  • 360 degree operation
  • Wireless Controller
Part Number: FFM‐HYPERION‐D6

Description

FEATURES

The Hyperion D Series is the world’s first variable upshot and that’s only half the fun.

A STEP ABOVE THE REST

What is Variable output?  That means you can control the size of your plume!  You can get 1-30 feet from one machine.  On top of that the Hyperion D Series features Froggy’s Instant Stop Technology (IST).  This pulls fluid from the core to reduce spitting and allow for 360 degree placement.  Although not as fast as the SJ8, the D Series is still faster than the competitors when it comes to output and cutoff.

ANY COLOR YOU LIKE

The Dual Layer HEX LED’s allow you not only to create any color you like, but also create an incredible dual flame effect.  The 3 and 5 pin DMX controllable RGBAW+UV LED’s give you an endless palette of combinations.

WORLD’S FIRST VARIABLE OUTPUT UPSHOT FOGGER

Make your columns of fog as tall or as short as you like!

INSTANT STOP TECHNOLOGY (IST) – PULLS FLUID OUT OF CORE TO REDUCE SPITTING AND GIVE PRECISE FOG OUTPUT

These machines go when you say “go” and stop when you say “stop.” Stop your fog effects as quickly as you start them.

DUAL ZONE LED – INNER AND OUTER FLAME TECHNOLOGY

Get the exact look you want with controllable lighting effects.

MAX HEIGHT: 30’

Shoot plumes of fog higher than a house! Visibility will never be a concern with these machines, even in large venues!

HEX COLORED LED – RGBAW+UV • 360 DEGREE OPERATION

Any color, any direction. The Hyperion machines give you full control of all your effects. UV LEDs allow for those awesome blacklight events.

REVERSIBLE TANK MOUNTING

Flexible mounting solutions offer you more freedom in your setup.

DOUBLE THE LED’S OF MOST UPSHOTS

Here at Froggy’s, we try to do everything bigger and better than the competition. The Hyperion machines are no exception! More LEDs means more powerful and intense lighting effects.

LOW FLUID SENSING WITH AUTO SHUT-OFF

Don’t worry about your machine running dry. The Hyperion has built-in sensors to let you know when levels are low. Intelligent sensors will automatically shut off the fluid pump to ensure reliable operation in the future.

LOCKING 20 A TRUE MAINS CONNECTOR WITH BREAKING CAPACITY (CBC)

Safe, convenient, and worry-free operation!

FULL CONTROL WITH 17 CHANNELS OF DMX

Easily integrate the Hyperion with any existing DMX setup.

WIRELESS CONTROL

Start and stop operation with the touch of a button- even at a distance!

SPECIFICATIONS

Physical
Length: 16.5 in. Box: 19.5 in.
Width: 15 in. Box: 18 in.
Height: 8 in. Box: 10.25 in.
Net Weight: 35.3 lbs Gross Weight: 38.6 lbs.

Performance
Fluid consumption (100%): 160 ml/min
Maximum operating time, maximum output: 15.6 min
Ready time: 4 Min.

Control and Programming
Control options: DMX, LCD Control Panel
Fog Variable output control, 0-100%
DMX channels: 17
External fluid control: Fluid sensing

Construction
Housing: Steel and aluminum
Color: Black
Fluid pump: Dual oscillating piston, high pressure
Fluid reservoir: 2.5L drop-in reservoir

Installation
Mounting: Standing or hanging
Orientation: 360 Deg.

Connections
AC Power: Seetronic Powerkon IP65
DMX, link mode in/out: 3 and 5-pin locking XLR

Electrical
US Model:AC power: 120 V, 60 Hz
Main fuse: 15A, 250 V
Typical power and current: 1600 W

*Measurements made at nominal voltage. Allow for a deviation of +/- 10%.:

Included Items
Fluid reservoir, 2.5L Tank
Power input cable: Seetroic Powerkon IP65

Accessories

Fog Scent Additives

Approved fluids*:
Bog Fog

QuikBlast

Backwood Bay

Technofog

Velcocity

*Various sizes available – contact us or see ‘Fluids’ product pages for details
