The Hyperion D Series is the world’s first variable upshot and that’s only half the fun.
A STEP ABOVE THE REST
What is Variable output? That means you can control the size of your plume! You can get 1-30 feet from one machine. On top of that the Hyperion D Series features Froggy’s Instant Stop Technology (IST). This pulls fluid from the core to reduce spitting and allow for 360 degree placement. Although not as fast as the SJ8, the D Series is still faster than the competitors when it comes to output and cutoff.
ANY COLOR YOU LIKE
The Dual Layer HEX LED’s allow you not only to create any color you like, but also create an incredible dual flame effect. The 3 and 5 pin DMX controllable RGBAW+UV LED’s give you an endless palette of combinations.
WORLD’S FIRST VARIABLE OUTPUT UPSHOT FOGGER
Make your columns of fog as tall or as short as you like!
INSTANT STOP TECHNOLOGY (IST) – PULLS FLUID OUT OF CORE TO REDUCE SPITTING AND GIVE PRECISE FOG OUTPUT
These machines go when you say “go” and stop when you say “stop.” Stop your fog effects as quickly as you start them.
DUAL ZONE LED – INNER AND OUTER FLAME TECHNOLOGY
Get the exact look you want with controllable lighting effects.
MAX HEIGHT: 30’
Shoot plumes of fog higher than a house! Visibility will never be a concern with these machines, even in large venues!
HEX COLORED LED – RGBAW+UV • 360 DEGREE OPERATION
Any color, any direction. The Hyperion machines give you full control of all your effects. UV LEDs allow for those awesome blacklight events.
REVERSIBLE TANK MOUNTING
Flexible mounting solutions offer you more freedom in your setup.
DOUBLE THE LED’S OF MOST UPSHOTS
Here at Froggy’s, we try to do everything bigger and better than the competition. The Hyperion machines are no exception! More LEDs means more powerful and intense lighting effects.
LOW FLUID SENSING WITH AUTO SHUT-OFF
Don’t worry about your machine running dry. The Hyperion has built-in sensors to let you know when levels are low. Intelligent sensors will automatically shut off the fluid pump to ensure reliable operation in the future.
LOCKING 20 A TRUE MAINS CONNECTOR WITH BREAKING CAPACITY (CBC)
Safe, convenient, and worry-free operation!
FULL CONTROL WITH 17 CHANNELS OF DMX
Easily integrate the Hyperion with any existing DMX setup.
Start and stop operation with the touch of a button- even at a distance!
Length: 16.5 in. Box: 19.5 in.
Width: 15 in. Box: 18 in.
Height: 8 in. Box: 10.25 in.
Net Weight: 35.3 lbs Gross Weight: 38.6 lbs.
Fluid consumption (100%): 160 ml/min
Maximum operating time, maximum output: 15.6 min
Ready time: 4 Min.
Control and Programming
Control options: DMX, LCD Control Panel
Fog Variable output control, 0-100%
DMX channels: 17
External fluid control: Fluid sensing
Housing: Steel and aluminum
Fluid pump: Dual oscillating piston, high pressure
Fluid reservoir: 2.5L drop-in reservoir
Mounting: Standing or hanging
Orientation: 360 Deg.
AC Power: Seetronic Powerkon IP65
DMX, link mode in/out: 3 and 5-pin locking XLR
US Model:AC power: 120 V, 60 Hz
Main fuse: 15A, 250 V
Typical power and current: 1600 W
*Measurements made at nominal voltage. Allow for a deviation of +/- 10%.:
Fluid reservoir, 2.5L Tank
Power input cable: Seetroic Powerkon IP65
Fog Scent Additives
*Various sizes available – contact us or see ‘Fluids’ product pages for details
